Design & Install By Elevator Model

Stanley’s expert elevator installation team has an elevator model that will fit any building. Whether commercial or residential building, low-rise or high-rise, Stanley can design, scope, and install an elevator based on your individual requirements. For more information on what elevator model will work best for you, Contact Us or see information on specific model types below:

Hydraulic

Endura A – Holeless “Above Ground” Models

Endura A: Single Stage Holeless Elevators (for standard travel up to 12’-8’’, extended travel to 18’-11’’)
http://www.thyssenkruppelevator.com/elevator-products/twinpost-above-ground-1-stage

Endura A: Two-Stage Holeless Telescoping Elevators (for standard travel up to 23’-2’’, extended travel to 28’-6’’)
http://www.thyssenkruppelevator.com/elevator-products/twinpost-above-ground-2-stage

Endura A: Three-Stage Holeless Telescoping Elevators (for standard travel up to 33’-6’’, extended travel to 48’-3’’)
http://www.thyssenkruppelevator.com/elevator-products/twinpost-above-ground-3-stage

Endura B – Holeless “Below Ground” Models
http://www.thyssenkruppelevator.com/elevator-products/below-ground

Machine Room-Less (MRL) Models

Synergy Self-Supported: Standard Series

http://www.thyssenkruppelevator.com/elevator-products/self-supported

Self-supporting MRLs are ideal for wood-framed buildings, existing construction, or structures not intended to carry the loads of an elevator system.  Elevator loads are transferred from machine at the top of the hoistway to the guide rails, ending in the pit floor below. Compact and lightweight, Self Supported MRLs are the most economical way to outfit your building with energy efficient traction performance.

  • Small footprint: Fits into a standard hydraulic hoistway
  • Up to 85’-0” travel
  • Side-mounted counterweight (allows for front and rear door openings)
  • Speed: 150 fpm
  • Capacity: 2100 – 3500 lbs.
  • Offers limited aesthetic options

Synergy Building Supported: Standard Series

http://www.thyssenkruppelevator.com/elevator-products/building-supported-standard-series

Synergy Building Supported models rely on additional structure in your building for support. This can be accomplished by pockets in a masonry hoistway wall or steel beams at the top of the shaft. Though Building Supported models require additional cost and coordination up-front, they allow for a much greater range of speeds, travel distance, capacities, and aesthetic options.

The Building Supported Standard Series MRL offers additional capacities, speeds, and travel over the Self Supported models. Weights and options are more flexible due to a larger motor, which allows for a wider range of panels, ceilings, or flooring styles in your elevator cab. The Building Supported Standard series is the perfect solution for projects that require upgraded performance and finishes without the need for major engineering or custom equipment.

  • Up to 300’-0” travel
  • Side or rear mounted counterweight
  • Speed: 200 – 350 fpm
  • Capacity: 2100 – 4000 lbs.
  • Offers a medium range of cab & signal options

Synergy Building Supported: Performance Series

http://www.thyssenkruppelevator.com/elevator-products/building-supported-performance-series

Synergy Building Supported models rely on additional structure in your building for support. This can be accomplished by pockets in a masonry hoistway wall, or steel beams at the top of the shaft. Though Building Supported models require additional cost and coordination up-front, they allow for a much greater range of speeds, travel distance, capacities, and aesthetic options.

The Performance Series synergy equipment offers the widest range of speeds, capacities, and aesthetic options. They can be provided in hospital configurations with large cabs, and can even be engineered to accommodate non-standard hoistways. Though the Performance Series uses a larger motor and requires machine beams, the options and customization available make this model ideal for the most demanding elevator projects.

  • Up to 300’-0” travel
  • Side or rear mounted counterweight
  • Machine beams required
  • Speed: 200, 350 & 500 fpm
  • Capacity: 2100 – 5000H, with engineered configurations available
  • Unlimited aesthetic options
Traction Models

Momentum Standard series

http://www.thyssenkruppelevator.com/elevator-products/standard-series

The Momentum Standard series traction elevator features a mini-AC gearless motor mounted in a machine room above the elevator hoistway.  Momentum elevators deliver the speed and performance necessary for high rise buildings in an energy-efficient package.   Though space is required for an overhead machine room, the elevator equipment is much easier to access for maintenance.  The Momentum Standard series is ideal for:

  • Buildings with travel up to 300′-0″
  • Speeds of 350 to 500 fpm
  • Capacities up to 5000 lbs.
  • Standard or Premium Cab finishes

Momentum Performance series

http://www.thyssenkruppelevator.com/elevator-products/performance-series

The Momentum Performance Series is the perfect application for high rise buildings that demand custom solutions such as increased speeds or unique cab configurations.  This model’s powerful gearless machine, located in an elevator machine room above the hoistway, can be engineered to provide vertical transportation solutions to some of the tallest buildings in the world.  The Momentum Performance series is ideal for:

  • Buildings with travel 300’-0’’ and above
  • Standard speeds of 700 to 1,200 fpm, with higher speeds available
  • Capacities up to 5000 lbs
  • Standard or Premium cab finishes and flooring
